SA-CA-010 · Reference Configuration
Insulated Canadian Winter Cabin Sauna
- Nordic
- 5–6 people
- Electric
- Thermowood
- ≈8–10.5 kW electric heater class
- High-performance envelope
- Minimal glazing for low heat loss
- 10 × 8 ft reference footprint
Foundation profile
Ground Screws
| Principle | Steel screw piles driven below the frost line carry the structure on point supports. |
|---|---|
| Suitability | Most framed cabins, cubes, pods and sheds, especially where the floor should sit clear of snow. |
| Soils | Work in a wide range of soils; length and number are matched to ground conditions. |
| Frost heave | Excellent — piles reach below the frost line, so seasonal heave has little grip on them. |
| Drainage | Very good — the structure is lifted, leaving air and drainage beneath the floor. |
| Build difficulty | Intermediate |
Ground screws are the archive’s go-to cold-climate foundation: steel piles driven below the frost line that lift the floor clear of snow with minimal disturbance. They suit most framed cabins, cubes, pods and sheds.
